The Mitsubishi PS21963-4S is a DIP-type Intelligent Power Module combining a full three-phase IGBT inverter bridge with integrated gate drive circuits, bootstrap power supply, and comprehensive on-chip protection into a single compact package. The IPM architecture reduces external component count, simplifies PCB layout, and accelerates time-to-market for drive designers. Built-in protection functions — including undervoltage lockout, overcurrent shutdown, and overtemperature detection — are handled internally, offloading critical fault management from the host controller and improving system-level reliability in demanding environments.

The PS21963-4S is widely deployed in fractional to low-kilowatt variable-frequency drives (VFDs), HVAC compressor inverters, pump and fan motor controls, small industrial servo systems, and home appliance inverter platforms. Its self-contained gate drive and protection architecture makes it a preferred choice for OEM equipment manufacturers and field service engineers replacing modules in legacy inverter boards. The part is fully compatible with microcontroller and DSP PWM outputs, enabling direct integration into modern digital control platforms without additional isolated gate drive stages.

Quick Reference: PS21963-4S

Key Features of the PS21963-4S:

• Integrated three-phase low-side and high-side IGBT bridge with bootstrap-compatible internal gate drive circuitry
• Built-in undervoltage lockout (UVLO) on all six gate drive channels for reliable startup and fault prevention
• On-chip overcurrent protection (OCP) with fault output signal for direct interface to host microcontroller or DSP
• Thermal shutdown protection with fault signaling reduces external thermistor and comparator circuitry requirements
• DIP inline package with isolated baseplate facilitates direct heatsink mounting and simplified PCB integration
• Compatible with 3.3 V and 5 V logic-level PWM inputs, enabling direct interface to modern DSP and MCU platforms without additional level-shifting hardware

With a current factory lead time of 99 weeks, the PS21963-4S presents a significant procurement challenge for production lines, MRO stocking programs, and emergency equipment repairs. Mitsubishi IPMs in the PS21963 family are widely used in installed equipment that remains in service well beyond original production cycles, making aftermarket availability essential. Engineers managing aging drive platforms or sustaining legacy OEM product lines cannot afford to wait two years for factory delivery — having a trusted distributor with verified stock is the only practical solution when downtime or schedule risk is unacceptable.

ATI Accurate Technology, based in Palmetto, Florida, stocks the PS21963-4S as new OEM product and ships same-day on orders placed before 5PM EST. ATI specializes in hard-to-find, long-lead-time, and obsolete power semiconductors including IGBTs, thyristors, diodes, and intelligent power modules. Volume pricing is available for production and MRO orders. Contact ATI today at 239-734-7566 or sales@igbts.us to confirm availability and get a quote.
