The Mitsubishi PM100CVA120-2 is a sixth-generation Intelligent Power Module combining 1200V, 100A IGBT technology with integrated gate drive and protection circuits in a single, thermally efficient package. Designed to reduce component count and board space, this IPM includes built-in overcurrent, short-circuit, under-voltage lockout, and over-temperature protection with isolated fault output signaling. Its optimized IGBT chip design delivers low saturation voltage (V_CE(sat)) and fast, controlled switching transitions, making it a high-performance solution for engineers designing compact, reliable power conversion systems.

The PM100CVA120-2 is widely deployed in variable-frequency drives (VFDs), servo amplifiers, UPS systems, induction heating equipment, and industrial robotics. Its integrated protection and fault feedback simplify control board design, reducing development time for OEM drive manufacturers. The module's robust isolated baseplate construction supports direct mounting to heatsinks in high-cycle industrial environments. Applications in HVAC compressor drives, CNC spindle drives, and elevator inverters benefit from the module's combination of switching efficiency and on-chip protection that minimizes the risk of catastrophic failure during fault conditions.

Quick Reference: PM100CVA120-2

Key Features of the PM100CVA120-2:

• 1200V / 100A IGBT-based Intelligent Power Module in a compact isolated package
• Integrated gate drive circuit eliminates external gate resistor networks and simplifies PCB layout
• On-chip protection: overcurrent (SC protection), under-voltage lockout (UVLO), and over-temperature shutdown
• Isolated fault output pin provides real-time fault signaling to the system controller for fast system-level response
• Low V_CE(sat) IGBT technology reduces conduction losses and improves overall inverter efficiency
• Thermally optimized isolated baseplate design compatible with standard heatsink mounting and thermal interface materials

With a factory lead time of 40 weeks on new production, the PM100CVA120-2 is a chronic supply chain challenge for maintenance teams managing unplanned downtime and OEM drive manufacturers managing production schedules. Whether you're replacing a failed module in a critical VFD on the plant floor or building inventory buffer stock against ongoing semiconductor lead time volatility, waiting on new production is rarely an option. ATI Accurate Technology maintains ready stock of the PM100CVA120-2 as new OEM product, enabling immediate procurement without factory queue delays — a direct answer to long-lead obsolescence risk in your power electronics supply chain.

ATI Accurate Technology is a power semiconductor specialist headquartered in Palmetto, Florida, stocking IGBTs, IPMs, thyristors, diodes, and rectifier modules including hard-to-find and long-lead-time parts. Orders placed before 5PM EST ship same day. Contact our team for volume pricing, cross-reference support, or technical questions: 239-734-7566 | sales@igbts.us.
