The Mitsubishi PM100CVA060 is a sixth-generation Intelligent Power Module combining 600V, 100A IGBT switching elements with integrated gate drive circuitry, fault protection logic, and a thermistor interface in a single compact package. Designed to minimize external component count and development time, the PM100CVA060 incorporates undervoltage lockout, overcurrent shutdown, and overtemperature protection functions internally — reducing system-level complexity and improving overall converter reliability. Its low-inductance package and optimized internal layout support high switching frequencies with reduced EMI, making it a preferred choice for high-performance inverter designs.

The PM100CVA060 is widely deployed in variable frequency drives (VFDs), AC servo amplifiers, industrial motor controllers, elevator and crane drives, HVAC compressor inverters, and regenerative power supplies. Its integrated protection functions reduce design overhead in safety-critical industrial environments where uptime and fault tolerance are paramount. OEMs building general-purpose inverters in the 15–30kW range frequently specify this module, as do field service teams maintaining legacy equipment where direct form-fit-function replacement is required without redesign.

Quick Reference: PM100CVA060

Key Features of the PM100CVA060:

• 600V collector-emitter voltage and 100A continuous collector current rating suitable for mid-power industrial inverter stages
• Integrated gate drive circuitry eliminates discrete driver components and reduces PCB real estate and BOM complexity
• Built-in protection functions: overcurrent (OC) shutdown, undervoltage lockout (UVLO), and overtemperature (OT) fault with dedicated fault output pin
• Internal thermistor (NTC) output provides real-time junction temperature monitoring for system-level thermal management
• Optimized low-inductance package minimizes stray inductance for reduced switching voltage spikes and improved switching waveform quality
• Compatible with Mitsubishi's standard IPM gate drive interface, enabling direct drop-in replacement in existing designs

With Mitsubishi's current factory lead time on the PM100CVA060 running at 39 weeks, procurement teams sourcing for production builds or emergency MRO replacements face significant exposure. Legacy equipment using this module cannot wait three-quarters of a year for a repair part. ATI maintains inventory of the PM100CVA060 precisely to address this gap — providing new OEM units immediately available for shipment, eliminating lead-time risk for both scheduled maintenance and unplanned downtime events. Whether you need a single unit or a blanket order quantity, ATI can support your timeline.

ATI Accurate Technology is a power semiconductor distributor based in Palmetto, Florida, stocking hard-to-find and long-lead-time devices including IGBTs, IPMs, thyristors, diodes, and rectifier modules. Orders placed before 5PM EST ship same day. Contact our team for volume pricing, cross-reference assistance, or technical support: call 239-734-7566 or email sales@igbts.us. Visit igbts.us to check live inventory and request a quote.
