The Mitsubishi CM75TU-24F is a 75A, 1200V IGBT module engineered for demanding power switching applications where efficiency, thermal stability, and switching speed are critical. Part of Mitsubishi's proven TU-series lineup, this module integrates an IGBT with a fast-recovery freewheeling diode in a compact, industry-standard package. Its low saturation voltage and optimized gate charge characteristics make it well-suited for high-frequency PWM operation in industrial converters, reducing switching losses and improving overall system efficiency across a wide load range.

The CM75TU-24F sees broad deployment in industrial AC motor drives, servo amplifier outputs, regenerative inverters, uninterruptible power supplies, and induction heating equipment. Engineers specify this module where a balance of current capacity, blocking voltage, and switching speed is essential for reliable continuous-duty operation. Its robust construction supports the thermal cycling demands of variable-speed drive applications, and the industry-standard footprint simplifies drop-in replacement in existing drive platforms without mechanical redesign or PCB modification.

Quick Reference: CM75TU-24F

Key Features of the CM75TU-24F:

• 1200V collector-emitter blocking voltage (VCES) suitable for 690VAC line-side applications
• 75A continuous collector current rating with high peak current capability for overload tolerance
• Low VCE(sat) minimizes conduction losses during continuous PWM switching duty
• Integrated fast-recovery anti-parallel freewheeling diode reduces external component count
• Isolated baseplate construction for direct heatsink mounting and simplified thermal management
• Industry-standard TU-series package footprint enables direct replacement in existing drive designs

With a 42-week factory lead time on new production, the CM75TU-24F is a chronic bottleneck for maintenance teams managing unplanned drive failures and for procurement professionals building safety stock. A single failed module can take a production line offline for the better part of a year if stock isn't on hand. ATI Accurate Technology specializes in sourcing exactly these kinds of long-lead-time, hard-to-find Mitsubishi IGBT modules, maintaining inventory that lets engineers address critical failures in hours rather than months.

ATI Accurate Technology is headquartered in Palmetto, Florida and ships the CM75TU-24F same day on orders placed before 5PM EST. Whether you need a single replacement unit for an emergency repair or volume quantities for planned maintenance stock, ATI can support your requirement. Contact our power semiconductor specialists at 239-734-7566 or sales@igbts.us for real-time availability, volume pricing, and application support.
