The Fuji 1MBH60D-100 is a single-configuration Insulated Gate Bipolar Transistor (IGBT) module rated for 60 amperes continuous collector current and 1000 volts blocking voltage. Engineered to Fuji Electric's established power module standards, this device delivers the high-efficiency switching characteristics and thermal stability that industrial power electronics designers depend on. Its single-switch topology simplifies integration into custom gate-drive and protection circuits, making it a versatile building block for both OEM equipment design and field replacement in legacy installations where the original part must be matched exactly.

The 1MBH60D-100 is well suited for a broad range of industrial power conversion platforms. Common applications include variable-frequency motor drives, servo amplifiers, induction heating inverters, industrial UPS systems, and welding power supplies operating on 600V or higher DC bus rails. Its 1000V voltage class provides the necessary margin for 690VAC line-connected systems after rectification transients are accounted for. Engineers specifying or replacing this module in steel mills, HVAC systems, oil and gas pumping equipment, and automated manufacturing cells will find its 60A rating appropriate for mid-range drive power stages.

Quick Reference: 1MBH60D-100

Key Features of the 1MBH60D-100:

• 60A continuous collector current rating with 1000V CE breakdown voltage, providing robust margin on 600V-class DC bus systems
• Single-switch module topology enabling flexible half-bridge, chopper, and custom converter circuit configurations
• Low V_CE(sat) characteristic reduces conduction losses and minimizes heat sink requirements in thermally constrained enclosures
• Integrated freewheeling diode optimized for fast recovery, reducing reverse-recovery losses during high-frequency switching transitions
• Isolated baseplate construction supports direct mounting to heatsink with standard power module thermal interface materials
• Compatible with Fuji Electric's established gate-drive voltage and resistance recommendations, simplifying drop-in replacement in existing drive platforms

With a factory lead time of 99 weeks on new production, the 1MBH60D-100 presents a significant procurement challenge for maintenance teams and OEM service depots that cannot afford extended downtime. This part belongs to a generation of Fuji IGBT modules that are increasingly difficult to source through standard distribution channels. Equipment dependent on this device — including legacy servo and spindle drives — may face prolonged outages if replacement stock is not secured proactively. ATI Accurate Technology maintains inventory of hard-to-find, long-lead-time, and obsolete power semiconductors specifically to address these supply chain gaps.

ATI Accurate Technology is headquartered in Palmetto, Florida, and stocks the 1MBH60D-100 as a new OEM component available for same-day shipment on orders placed before 5PM EST. Whether you need a single replacement module or volume quantities for a scheduled maintenance program or production run, ATI can support your requirements. Contact our team directly for pricing, lead time confirmation, and volume discount availability. Call 239-734-7566 or email sales@igbts.us.
